Physical Design (PD)
Our Physical Design (PD) services cover the complete backend implementation flow from netlist to GDSII. We specialize in floorplanning, placement, CTS, routing, power optimization, timing closure, and sign-off checks for complex ASIC and SoC designs across advanced semiconductor technology nodes.
Key Capabilities
- 1 Floorplanning, power planning & macro placement
- 2 Placement & optimization using industry-standard tools
- 3 Clock Tree Synthesis (CTS) and routing
- 4 Timing, IR drop, EM & power sign-off checks
- 5 Final GDSII generation & tape-out readiness
Our team ensures robust backend implementation with optimized power, performance, and area (PPA) while meeting all sign-off requirements for reliable silicon results.
Why Choose Our Physical Design Services?
With extensive knowledge of deep-submicron technologies, sign-off methodologies, and advanced PPA optimization, we deliver high-quality PD solutions ready for tape-out across major foundries.
Advanced PPA Optimization
Achieving timing closure with optimal power and area across complex designs.
Foundry-Compliant Sign-Off
Expertise in DRC, LVS, IR drop, EM, STA, and other essential checks.
Cutting-Edge Tools
Experience with Synopsys, Cadence, and Siemens backend tools.
Complete Backend Flow
From netlist handoff to GDSII delivery with high-quality implementation.
Our PD flow includes floorplanning, power planning, placement optimization, CTS, routing, timing closure, DRC/LVS checks, and sign-off verification for tape-out-quality layouts.
We work with industry-standard tools including Cadence Innovus, Synopsys ICC2, PrimeTime, Voltus, RedHawk, Calibre, and Pegasus to achieve best-in-class PD results.
Specialized in high-speed blocks, low-power implementations, hierarchical PD flows, multi-voltage designs, advanced nodes (5nm, 7nm, 12nm, 16nm), and full-chip sign-off.
